Description
Category: DC Fan
Manufacturer’s Part Number: THB1748BG-9L77
Manufacturer: for delta Electronics
Description: FAN 48VDC 170X170X56MM
Minimum Order Quantity: 1
Series: THB
Voltage-rated: 48VDC
Size/Size: Round – 172mm diameter x 50.8mm wide
Air flow: 607.0 CFM (17.19 m?/min)
Static pressure: 4.136 inch water column (1030.3 Pa)
Bearing type: double ball
Fan Type: Pipe Shaft Type
Characteristic: PWM control; Speed sensor (tachometer)
Noise: 75 dB (A)
Power (W): 168W
RPM: 8000 RPM
End connection: 4 leads
Weight: about 2 pounds (907.2g)
Working temperature: 14 ~ 158 F (- 10 ~ 70 C)
Additional information
| Weight | 1 kg |
|---|---|
| Brand Name | DELTA |
| Application | Computer Case |
| Bearing | Two Ball Bearing |
| Fan Life | 50000 hrs |
| Lines | 4 Lines |
| Type | Fan |
| Model Number | THB1748BG |
