Description
Weight
1 kg
Fan size
0 mm
Blade material
PA plastic
Fan housing material
PP plastic
Number of blades
5
Airflow direction
“V”
Direction of rotation
Counterclockwise, viewed toward rotor
Degree of protection
IP55
Insulation class
“B”
Moisture (F) / Environmental (H) protection class
H1
Max. permitted ambient temp. for motor (transport/storage)
+ 80 °C
Min. permitted ambient temp. for motor (transport/storage)
– 40 °C
Installation position
Any
Condensation drainage holes
None
Mode
S1
Motor bearing
Ball bearing
Technical features
– Thermal overload protection for motor – Soft start – Speed selection max./min.
Speed levels
2
EMC immunity to interference
According to EN 61000-6-2 (industrial environment)
EMC circuit feedback
According to EN 61000-3-2/3
EMC interference emission
According to EN 61000-6-3 (household environment)
Touch current according to IEC 60990 (measuring circuit Fig. 4, TN system)
<= 0,25 mA Motor protection Thermal overload protector (TOP) internally connected with cable Lateral Protection class II Conformity with standards EN 60335-1; EN 60335-2-24; EN 60335-2-80; EN 60335-2-89 / CE Approval EAC / UL 1004-3 / CSA C22.2 No. 77 / VDE
Additional information
| Weight | 1 kg |
|---|---|
| Type | CPU Fan with Heatsink |
| Model | W1G200-EC91-27 |
| MPN | W1G200-EC91-27 |
| Brand | EBM PAPST |
| UPC | Does not apply |
| Motor | M1G055-BD |
