Description
The Sanyo Denki 109R0848K4D07 is a compact DC Axial Fan measuring 80x80x25mm. It operates on 48VDC with a rated current of 0.100A and a power consumption of 4.8W, delivering a high airflow of 55.1CFM and a static pressure of 88.4Pa. The fan features a durable ball bearing system and includes locked rotor protection and a speed sensor, making it an ideal cooling solution for various high-reliability industrial and electronic applications.
109R0848K4D07 Fan Parameters
Model: 109R0848K4D07
Manufacturer: Sanyo Denki
Type: DC Axial Fan
dimensions: 80 x 80 x 25 mm
Rated Voltage: 48 V DC
Operating Voltage Range: 40.8 to 55.2 V DC
Rated Current: 0.100 A
Rated Input Power: 4.8 W
Rated Speed: 4600 RPM
Airflow: 55.1 CFM (1.54 m³/min)
Static Pressure: 88.4 Pa (0.355 in H₂O)
Noise: 41.0 dB(A)
Bearing Type: Ball Bearing
Expected Life: 40000 hrs @ 60°C
Operating Temperature: -20 to 60 °C
Features: Locked Rotor Protection, Speed Sensor (Tachometer)
Termination Style: 3-wire leads
Weight: 110.22 g
Approvals: CCC, CE, CSA, EAC, UL, VDE
Application
The 109R0848K4D07 is designed for applications where high performance, reliability, and precision monitoring are crucial. It is well-suited for cooling servers, telecommunications equipment, power supplies, and control cabinets.
Additional information
| Weight | 0.5 kg |
|---|---|
| Compatible CPU | 1 |
| Brand Name | SANYO |
| Noise | 30dBA |
| Model Number | 109R0848K4D07 |
| Power Interface | 3pin |
| Heatsink Material | Copper & Aluminum |
| Air Volume | 45CFM |
| Application | Graphics Card |
| Lines | 3 Lines |
| Type | Fan |
| Power | 3W |
| Fan Life | 30000 hrs |
| Bearing | Two Ball Bearing |
| Package | No |
| Fan Speed Control | 3500RPM |
| Fan Size | 70*70*25 |
