Description
Model:6314/2TDHP
Brand:ebmpapst
Voltage Rating:24VDC
Dimensions:17.2×5.1×17.2cm
Height:172mm
Depth:51mm
Width:172mm
Airflow:353 CFM (10 m3/min)
Speed:5500 RPM
Bearing Type:Ball
Noise:60 dBA
IP Rating: IP20
Power Rating:40 W
Base/Housing Material:Aluminum
Operating Temperature:-20 to 70 °C
Power Rating:40.0000 W
Product Diameter:171.5 mm
Product Dimensions:50.8 mm
Termination:Lead Wire
Features: Speed Signal, Open Collector Output
Housing Material: Aluminum
Termination Style: Wire Leads – 4
Series: 6300TD
Features：
3-phase fan drive high degree of running smoothness
Very rigid compression curve for high air flow at high back pressure
Low operating noise level at high back pressure
Standard with PWM control input and speed signal, additional inputs and outputs
Material: aluminium housing, fiberglass-reinforced PA impeller; housing with grounding lug for screw M4 x 8 (Torx)
Protected against reverse polarity and locking
Connection via single strands AWG 20, TR 64. Bared and tin-plated
Air exhaust over struts. Direction of rotation counter-clockwise, seen on rotor
Mass: 910 g.
Additional information
| Weight | 1 kg |
|---|---|
| Type | 6314/2TDHP |
| Nominal voltage | 24VDC |
| Nominal voltage range | 16 ..36VDC |
| Speed (rpm) | 5500min-1 |
| Power consumption | 410W |
| Min. ambient temperature | -20°C |
| Max. ambient temperature | 75°C |
| Air flow | 600m3/h |
| Sound power level | 7.3B |
| Sound pressure level | 60dB(A) |
| General description | 3-phase fan drive with |
| Weight | 0.910 kg |
| Dimensions | Ø 172 x 51 mm |
| Impeller materiall | Glass-fiber reinforced PA plastic |
| Housing material | Die-cast aluminum |
| Airflow direction | Exhaust over struts |
| Direction of rotation | Counterclockwise, viewed toward rotor |
| Bearing | Ball bearing |
| Service life L10 at 40 °C | 75000 h |
| Service life L10 at maximum temperature | 30000 h |
| Cable | With leads AWG 18, 20 or AWG 22, TR 64, speed signal and control input AWG 22 Motor protection: Protection against reverse polarity and blocked rotor. |
