Description
Appearance Size: 150 × 150 × 50mm
Rated voltage: DC12V
Voltage Range: DC8.0-14.0V
Input Power: 1.80A (nominal current)
Rated speed: 3800 r.p.m
Temperature Range: -10 – 70 ° C
Estimated life expectancy: L10 life expectancy 50,000 hours at 25 ° C
Bearing Structure: Maintenance-free double ball bearing
Direction of rotation: The wind is discharged from the bracket and rotates counterclockwise facing the rotor
Wiring: + red – black signal: blue
Maximum air volume: 440.0 m3; / h
Motor Protection: overload protection, fault protection and blocking lock lock flow protection
Pressure: 123 Pa
Noise Index: 56.5 dB (A)
Additional information
| Weight | 1 kg |
|---|---|
| Lines | 4 Lines |
| Brand Name | delta |
| Power | 3.6W |
| Fan Life | 100000 hrs |
| Air Volume | 45CFM |
| Application | Computer Case |
| Power Interface | 4PIN |
| Type | Fan |
| Fan Speed Control | No RPM |
| Bearing | Two Ball Bearing |
| Model Number | AFC1512DG |
| Package | No |
| Fan Size | 150x150x50mm |
| Noise | 53dba |
