Description
Model:R2D225-AV02-15
Size: 225 mm
Material of impeller: Plastic PA6, fibreglass-reinforced
Number of blades: 7
Direction of rotation: Clockwise, seen on rotor
Type of protection: IP 44; Depending on installation and
position
Insulation class: “F”
Humidity class: F1-1
Mounting position: Any
Operation mode: S1
Motor bearing: Ball bearing
Touch current acc.IEC 60990 (measuring network Fig. 4, TN system): <0.75mA
Robot Rittal Cabinet fan
Additional information
| Weight | 5 kg |
|---|---|
| Model | R2D225-AV02-15, R2D225-AV02-12, R2D225-AV02-18, R2D225-AV02-24 |
| Brand | Ebmpapst |
| Type | Centrifugal Fan |
| Power | 115W |
| Place of Origin | Germany |
| Voltage | 400V |
| Speed | 2650min |
| Power consumption | 0.24A |
| blade diameter | 225 mm |
| Motor bearing | Ball bearing |
