Description
Model Number:R2E220-AB06-05
Manufacturer:ebm-papst
Place of Origin:Germany
Product Category:Blowers & Centrifugal Fans
Current Type:AC
Bearing Type:Ball Bearing
Voltage Rating:230 V
Bearing Type:Ball
Noise:75 DBA
Speed:3050 RPM
Height:220mm
Depth:220mm
Width:73mm
Housing Material:Polyamide (PA)
Termination Style:Wire Leads
Series:R2E220
IP Rating:IP44
Features:Backward Curved Fan Blades
Brand:ebm-papst
Weight:1.8kg
Base/Housing Material:Plastic
Maximum Airflow:530 (900.47 m3/hr) CFM
Additional information
| Weight | 2 kg |
|---|---|
| Type | R2E220-AB06-05 |
| Motor | M2E068-CF |
| Nominal voltage | 230VAC |
| Frequency | 50~60Hz |
| Speed (rpm) | 2700~3050min-1 |
| Power consumption | 85~115W |
| Current draw | 0.38~0.51A |
| Capacitor | 2.5µF |
| Capacitor voltage | 400VDB |
| Min. ambient temperature | -25 °C |
| Max. ambient temperature | 45°C |
| Starting current | 0.85A |
| Fan size | 220mm |
| Impeller material | PA plastic |
| Degree of protection | IP44 |
| Motor bearing | Ball bearing |
| Approval | CCC; EAC |
