Description
Model：R2E225-RA92-09
Manufacturer:ebm-papst
Voltage:230VAC
Blower Type:Centrifugal
AC or DC Operation: AC
Air Flow:1195m³/h
Series:R2E225
Height:252 mm
Depth:120 mm
Width:252 mm
Fan Speed:2500rpm
Bearing Type:Ball
Termination Style:Wire Leads
Weight: 5.805 lbs
Additional information
| Weight | 3 kg |
|---|---|
| Type | R2E225-RA92-09 |
| Motor | M2E068-DF |
| Nominal voltage | 230VAC |
| Frequency | 50~60Hz |
| Valid for approval / standard | CE |
| Speed | 2500~2600min-1 |
| Power input | 155~210W |
| Current draw | 0.68~0.92A |
| Motor capacitor | 3.5µF |
| Capacitor voltage | 450VDB |
| Min. ambient temperature | -25 °C |
| Max. ambient temperature | 70°C |
| Size | 225mm |
| Type of protection | IP 44; Depending on installation and position as per EN 60034-5 |
| Motor bearing | Ball bearing |
| Motor protection | Thermal overload protector (TOP) wired internally |
